Schneider smart plug with power metering

Information

Vendor: Tuya

Chip: BK7231N

Board: CB3S

Detailed: 0

Keywords: BL0942

Device Template

{
  "vendor": "Tuya",
  "bDetailed": "0",
  "name": "Schneider smart plug with power metering",
  "model": "550B6000",
  "chip": "BK7231N",
  "board": "CB3S",
  "flags": "1024",
  "keywords": [
    "BL0942"
  ],
  "pins": {
    "9": "Btn;1",
    "24": "LED;1",
    "26": "Rel;1"
  },
  "command": "startDriver BL0942",
  "image": "https://obrazki.elektroda.pl/5157340400_1706708868.jpg",
  "wiki": "https://www.elektroda.com/rtvforum/viewtopic.php?p=20937705"
}

Pins

- P9 is Btn on channel 1
- P24 is LED on channel 1
- P26 is Rel on channel 1
- Flags are set to 1024
- StartupCommand is set to startDriver BL0942

Futher reading

Read detailed flashing guide and get help in device topic: English guide, see also Polish guide

Return to devices list.
